Summary#

Recently I experienced a bizzare issue where a FortiSwitch wasn’t supplying POE power to anything you plugged into it. Whether that be a wireless access point or other PoE devices were plugged in the switch would not supply power. Essentially the access points at this particular site went offline randomly with a log stating they left. Just grew some legs and dipped. Error logs were quiet as well.

This is what I can remember from that issue along with ways to fix it.

Troubleshooting#

Devices that don’t need PoE to power on functioned as expected. No PoE indicator on the switch ports within the GUI either for devices that needed it. There wasn’t a log indicating there was an issue with PoE on the switch. So, I thought it was the device we had plugged in.

Initally I thought this was an issue with the access point. So I asked that some spares be taken on site. But, later realized that was the wrong move.

I had someone on site move the port of the PoE device to multiple ports on the switch. But, no dice. Which made me think it was an issue with the switch and how it was supplying PoE.

I logged into the switch and got to work. I checked the PoE status on a random port to see what it would tell me using the following command.

diagnose switch poe status port11

Which provided the following output. I know for a fact this port should have PoE enabled on it. The temperature was as concerning as the Power-Status and the power metric. But, this only proved there was an issue somewhere.

Port(11) Power:0.00W,	Power-Status: Disabled
Power-Up Mode: Normal Mode
Remote Power Device Type: PD None
Power Class: 0
Defined Max Power: 0.0W, Priority: Low.
Voltage: 0.00V
Current: 0mA
Temperature: 275.00 Centigrade

Used the following command to get the Poe Firmware Version on the FortiSwitch. I read that 0.0.0.0 or 15.15.15.15 as the version number indicates there is a big issue with PoE on the switch.

get hardware status

The output; which has been redacted, inidicates there is an issue. The article I read stated that when we are faced with this we need to turn off the device for thirty minutes and turn it back on to see if PoE is either restored or that there is a Poe Firmware Version present after running the above command again.

...
Poe Firmware Version:15.15.15.15

After letting the FortiSwitch sit powered off for thirty minutes. PoE didn’t work and the same firmware version - 15.15.15.15 - was the value from the status command above.

I ran a debug report on the switch and created a support ticket with Fortinet. Replaced the switch with a cold backup we had on hand and went through their RMA process to get the defective switch replaced.

Below is the diagnose command I ran on the defective FortiSwitch to generate the report for Fortinet Support. This command outputs a bunch of information for Fortinet to look through so they can determine next steps. They also requested a backup of the FortiGates configuration.

diagnose debug report

The fix and recomendations from Fortinet can be found in The Fix section of this article. I didn’t work through further troubleshooting steps.

The Fix#

This is a lesson to keep multiple devices of the same model as cold backups for your gear. Which luckily in this case we did. So we replaced the switch, configured it, and confirmed everything worked.

Ultimately, the fix was to contact Fortinet Support after obtaining a debug and the data listed in the troubleshooting section. New switch was sent overnight and we needed to transfer the contract to the new switch in the support portal. The defective switch needed to be sent back to Fortinet.

Lessons Learned#

Sometimes there is no telling when something like this will happen. But, if you don’t get stingy with your support contracts and you’re willing to spend a little more for cold backups. You will be fine. Just pull as much information off of the device as you can for support, get the device replaced in the rack, and get it all fixed.

Fortinet will overnight this gear as long as the device is supported and under a support contract. So stay on top of renewals and the outage window will not be horrible.
