Oaxaca: Close an Open File
Summary#
I may have killed process before I closed the file. Mostly due to not reading. But, with this challenge I definately learned a better way of handling files that processes refuse to close. So this was a win for me.
This challenge from SadServes expects the solver to close the file without terminating the process. It even punishes us if we terminate the process instead of following directions. So, remember to read the directions. There are other things to be learned from this. But, read on and we’ll get there.
I loved this challenge and SadServers did a great job at exposing me to something new. Greate thanks to them for providing an environment where I can learn different methods for troubleshooting things like this before a Sr. Linux Administrator has to yell at me about the right way to do this!
Scenario#
Scenario: “Oaxaca”: Close an Open File
Level: Medium
Type: Fix
Access: Email
Description:
The file /home/admin/somefile is open for writing by some process. Close this
file without killing the process.
Root (sudo) Access: False
Test: lsof /home/admin/somefile returns nothing.
Time to Solve: 15 minutes.
Solution#
So, the solution to this is to close the file without killing the process. I
started all of this by checking on the process using the lsof command provided
for the test.
lsof /home/admin/somefile
This output for this command can be seen below. The file is open under PID 814
under the user admin.
With the consideration of needing to close the file without terminating the
process. I was curious to know why. In the A Little Rabbit Hole section I
explain how I followed the process heiarchy to see why I couldn’t close it.
Turns out the parent process will disconnect the user from the instance this is
run on. Killing the 814 process will result in the parent process just opening
the file again.
Given that I need to close the file without terminating the process. I needed to do a little research. This is where I learned about file descriptors (fd / FD).
File descriptors are non-negative integers that handle files or resources in
Unix or Linux operating systems. In this case this is indicated by 77w in the
FD column of the lsof output. The purpose of this is to serve as a
communications channel between user-space and kernel-space system calls for I/O
operations. In our case the file somefile is given a file descriptor of 77.
With the w added at the end of it. This indicates indicate the access mode for
this file. In this case FD 77 is given access mode write (w). Where 77
is the integer picked for the file within the order it was opened. This does not
necessarly change; to my knowledge, when the process it terminated either.
COMMAND PID USER FD TYPE DEVICE SIZE/OFF NODE NAME
bash 814 admin 77w REG 259,1 0 272875 /home/admin/somefile
To come back to the initial task at hand. I did a little research on how to
close files using the file descriptor ID. In this case it was 77. The
redirection operator >&- closes standard output. The hiphen - in this case
signifies closing the file descriptor specified.
exec 77>&-
Used the test command provided to determine if the output described initially still exists. In this case there is no output. So, I should be good to go.
lsof /home/admin/somefile
A Little Rabbit Hole#
I went down a small rabbit hole to determine why the challenge author didn’t want the user to terminate the process. Given that is what a lot of us are used to.
I decided to go through the process heiarchy to review this. So I decided to
first look at PID 814. Which is the process that opened the somefile file.
lsof -p 814
This showed some useful data. But, not all of it. It definately provided more context as to which files were being run in memory. But, I think I needed a little more.
COMMAND PID USER FD TYPE DEVICE SIZE/OFF NODE NAME
bash 814 admin cwd DIR 259,1 4096 2 /
bash 814 admin rtd DIR 259,1 4096 2 /
bash 814 admin txt REG 259,1 1234376 335 /usr/bin/bash
bash 814 admin mem REG 259,1 51696 1603 /usr/lib/x86_64-linux-gnu/libnss_files-2.31.so
bash 814 admin mem REG 259,1 346132 1406 /usr/lib/locale/C.UTF-8/LC_CTYPE
bash 814 admin mem REG 259,1 50 1412 /usr/lib/locale/C.UTF-8/LC_NUMERIC
bash 814 admin mem REG 259,1 3360 1577 /usr/lib/locale/C.UTF-8/LC_TIME
bash 814 admin mem REG 259,1 1519554 1405 /usr/lib/locale/C.UTF-8/LC_COLLATE
bash 814 admin mem REG 259,1 270 1410 /usr/lib/locale/C.UTF-8/LC_MONETARY
bash 814 admin mem REG 259,1 48 1409 /usr/lib/locale/C.UTF-8/LC_MESSAGES/SYS_LC_MESSAGES
bash 814 admin mem REG 259,1 34 1413 /usr/lib/locale/C.UTF-8/LC_PAPER
bash 814 admin mem REG 259,1 27002 3458 /usr/lib/x86_64-linux-gnu/gconv/gconv-modules.cache
bash 814 admin mem REG 259,1 1839792 1594 /usr/lib/x86_64-linux-gnu/libc-2.31.so
bash 814 admin mem REG 259,1 18688 1595 /usr/lib/x86_64-linux-gnu/libdl-2.31.so
bash 814 admin mem REG 259,1 187792 2300 /usr/lib/x86_64-linux-gnu/libtinfo.so.6.2
bash 814 admin mem REG 259,1 62 1411 /usr/lib/locale/C.UTF-8/LC_NAME
bash 814 admin mem REG 259,1 131 1404 /usr/lib/locale/C.UTF-8/LC_ADDRESS
bash 814 admin mem REG 259,1 47 1414 /usr/lib/locale/C.UTF-8/LC_TELEPHONE
bash 814 admin mem REG 259,1 23 1408 /usr/lib/locale/C.UTF-8/LC_MEASUREMENT
bash 814 admin mem REG 259,1 177928 1590 /usr/lib/x86_64-linux-gnu/ld-2.31.so
bash 814 admin mem REG 259,1 252 1407 /usr/lib/locale/C.UTF-8/LC_IDENTIFICATION
bash 814 admin 0u CHR 136,0 0t0 3 /dev/pts/0
bash 814 admin 1u CHR 136,0 0t0 3 /dev/pts/0
bash 814 admin 2u CHR 136,0 0t0 3 /dev/pts/0
bash 814 admin 77w REG 259,1 0 272875 /home/admin/somefile
bash 814 admin 255u CHR 136,0 0t0 3 /dev/pts/0
There is the -R flag for lsof. Which directs it to list the Parent Process
(PPID) for the process being listed as well.
lsof -p 814 -R
Looking at this shows the PPID for the somefile PID to be 589.
COMMAND PID PPID USER FD TYPE DEVICE SIZE/OFF NODE NAME
bash 814 589 admin cwd DIR 259,1 4096 2 /
bash 814 589 admin rtd DIR 259,1 4096 2 /
bash 814 589 admin txt REG 259,1 1234376 335 /usr/bin/bash
bash 814 589 admin mem REG 259,1 51696 1603 /usr/lib/x86_64-linux-gnu/libnss_files-2.31.so
bash 814 589 admin mem REG 259,1 346132 1406 /usr/lib/locale/C.UTF-8/LC_CTYPE
bash 814 589 admin mem REG 259,1 50 1412 /usr/lib/locale/C.UTF-8/LC_NUMERIC
bash 814 589 admin mem REG 259,1 3360 1577 /usr/lib/locale/C.UTF-8/LC_TIME
bash 814 589 admin mem REG 259,1 1519554 1405 /usr/lib/locale/C.UTF-8/LC_COLLATE
bash 814 589 admin mem REG 259,1 270 1410 /usr/lib/locale/C.UTF-8/LC_MONETARY
bash 814 589 admin mem REG 259,1 48 1409 /usr/lib/locale/C.UTF-8/LC_MESSAGES/SYS_LC_MESSAGES
bash 814 589 admin mem REG 259,1 34 1413 /usr/lib/locale/C.UTF-8/LC_PAPER
bash 814 589 admin mem REG 259,1 27002 3458 /usr/lib/x86_64-linux-gnu/gconv/gconv-modules.cache
bash 814 589 admin mem REG 259,1 1839792 1594 /usr/lib/x86_64-linux-gnu/libc-2.31.so
bash 814 589 admin mem REG 259,1 18688 1595 /usr/lib/x86_64-linux-gnu/libdl-2.31.so
bash 814 589 admin mem REG 259,1 187792 2300 /usr/lib/x86_64-linux-gnu/libtinfo.so.6.2
bash 814 589 admin mem REG 259,1 62 1411 /usr/lib/locale/C.UTF-8/LC_NAME
bash 814 589 admin mem REG 259,1 131 1404 /usr/lib/locale/C.UTF-8/LC_ADDRESS
bash 814 589 admin mem REG 259,1 47 1414 /usr/lib/locale/C.UTF-8/LC_TELEPHONE
bash 814 589 admin mem REG 259,1 23 1408 /usr/lib/locale/C.UTF-8/LC_MEASUREMENT
bash 814 589 admin mem REG 259,1 177928 1590 /usr/lib/x86_64-linux-gnu/ld-2.31.so
bash 814 589 admin mem REG 259,1 252 1407 /usr/lib/locale/C.UTF-8/LC_IDENTIFICATION
bash 814 589 admin 0u CHR 136,0 0t0 3 /dev/pts/0
bash 814 589 admin 1u CHR 136,0 0t0 3 /dev/pts/0
bash 814 589 admin 2u CHR 136,0 0t0 3 /dev/pts/0
bash 814 589 admin 77w REG 259,1 0 272875 /home/admin/somefile
bash 814 589 admin 255u CHR 136,0 0t0 3 /dev/pts/0
Now it’s time to review the PID 589 to see what files associated with this
process as well.
lsof -p 589
Turns out this was the gotty command. Which I think handles the connectivity
to the challenge. I made the mistake of terminating this process and I lost
connection to the challenge. Which was a big “uh oh…” for me.
This is sending TCP connections to a compute instance in us-east-2. So this may be either sending data or provding connectivity to the challenge console we get to run commands on.
COMMAND PID USER FD TYPE DEVICE SIZE/OFF NODE NAME
gotty 589 admin cwd DIR 259,1 4096 2 /
gotty 589 admin rtd DIR 259,1 4096 2 /
gotty 589 admin txt REG 259,1 13118554 13 /usr/local/gotty
gotty 589 admin mem REG 259,1 1839792 1594 /usr/lib/x86_64-linux-gnu/libc-2.31.so
gotty 589 admin mem REG 259,1 149520 1607 /usr/lib/x86_64-linux-gnu/libpthread-2.31.so
gotty 589 admin mem REG 259,1 177928 1590 /usr/lib/x86_64-linux-gnu/ld-2.31.so
gotty 589 admin 0r CHR 1,3 0t0 4 /dev/null
gotty 589 admin 1u unix 0x0000000055d53620 0t0 744 type=STREAM
gotty 589 admin 2u unix 0x0000000055d53620 0t0 744 type=STREAM
gotty 589 admin 3u a_inode 0,12 0 9450 [eventpoll]
gotty 589 admin 4r FIFO 0,11 0t0 819 pipe
gotty 589 admin 5w FIFO 0,11 0t0 819 pipe
gotty 589 admin 6u IPv6 823 0t0 TCP *:http-alt (LISTEN)
gotty 589 admin 7u IPv6 11620 0t0 TCP ip-10-1-11-234.us-east-2.compute.internal:http-alt->ip-10-1-0-123.us-east-2.compute.internal:37538 (ESTABLISHED)
gotty 589 admin 8u CHR 5,2 0t0 83 /dev/ptmx
Conclusion#
Used the check.sh script to confirm the solution was correct.
bash /home/admin/agent/check.sh
Should be good on this one. The check script provided the OK and when I
clicked Check Solution it also said it’s completed.
OK
I learned a little more about file descriptors (fd) in this challenge. Providing a less destructive method for closing files so I’m not terminating processes.
I went off on a little rabbit hole with this one. But, I wanted to see why they
didn’t want us to terminate the process. The parent process is what keeps the
connection to the compute instance is tied to this file and I got kicked out
when I killed it. Luckily these instances are generated. If anyone does this.
Just Destroy the server and start again.
